The efficient AETEK 640477 SD-201, Outdoor 2.5G PoE++ Surge Protector, 20KV/10KA, Hardened Grade IP67 is a 1 Channel, IEEE 802.3af/at/bt & UPoE, Protects against surges up to 20KV/10KA, Multi-Gig 10/100/1000/2500 Mbps.

Features:

• Supports 10M/100M/1G/2.5G bps Ethernet
• Complies with IEEE 802.3bt/at/af and UPoE standards
• Protects up to 20KV/10KA surge protection
• An LED that indicates a failure situation
• Metal enclosure with an IP67 rating
• Temperature range of -40 degrees to 185 degrees Fahrenheit

Specifications:

Standards and Certifications

• 802.3af / 802.3at / 802.3bt
• CE, FCC, VCCI, C-Tick
• ITU-T K.21, IEC-61643-21, IEC-61000-4-5, TIA-968-A (FCC Part68)

General

• Number of Ports: 1
• Connectors: 2 x RJ45
• Data transfer rate: 10M/100M/1G/2.5G bps
• Max Discharge Current (8/20us): 10KA
• Maximum Operation DC Voltage: 60VDC
• Maximum Operation DC Current: 1A for 2 pair, 2A for 4 pair, 95W maximum
• Line to Ground Protection Level (10/700us): 20KV
• Line to Line Protection Level: (10/700us): 4KV
• Clamping Voltage (Line to GND): 150V
• Clamping Voltage (Line to Line): 20V
• Insertion Loss @ 10MHz/100MHz: 1 dB
• Return Loss @ 10MHz/100MHz: -20db
• Response time: 1ns
• MTBF (Hours): 1,132,887
• Operating Altitude: 2,000 m (6,562 ft)

Dimensions: 7.33 x 1.97 x 1.26 inches

" A minimum order amount of $50 is required in order to Maintain Wholesale Price"

NEW IN THE BOX
