The rugged AETEK 643553 H42-042-91-150, Outdoor IP67/IK10 bt PoE Switch with Adjustable 24V/56VDC Passive PoE and 12V/24VDC Output is a 2 x IEEE 802.3bt PoE ports, 2 x 24V/56VDC Passive PoE ports, 2 x SFP uplink ports has 6KV PoE surge protection, 150 W PoE Power Budget, and IP67-Rated Aluminum Housing.

Features:

• IP67/IK10 rated heavy-duty Aluminum enclosure
• Two IEEE 802.3bt-compliant PoE ports with up to 90W each
• Two 24V/56VDC Passive PoE ports
• Two SFP 1.25G slots allow for daisy-chaining for long-range IP surveillance

Specifications:

Standards and Certifications

• 802.3af / 802.3at / 802.3bt
• CE, FCC, VCCI, C-Tick Class A
• EN62368-1, EN61000-4-5

General

• Number of Network Ports: 6
• Number of PoE++ Network Ports: 2
• Number of Passive PoE Network Ports: 2
• Number of SFP Ports: 2 x 1.25G
• Data transfer rate: 10/100/1000 Mbps
• Mac table: 4K
• Jumbo frames: 9,216 Bytes
• Switching capacity: 12 Gbps
• Forwarding capacity: 11.904Mpps
• Surge protection per PoE Port: 6KV
• Weather rating: IP67
• Vandal proof: IK10
• MTBF (Hours): 84,877
• Operating Altitude: 2,000 m (6,562 ft)

Power

• Input Voltage: 100~240VAC and 48-56VDC Backup Input Power
• Output Power (Port 1-2): PoE IEEE 802.3af (Max. 15.4W), PoE+ IEEE 802.3at (Max. 30W), PoE++ IEEE 802.3bt (Max. 90W)
• Output Power (Port 3-4): 24W @ 2-pair 24VDC, 48W @ 4-pair 24VDC, 56W @ 2-pair 56VDC, 90W @ 4-pair 56VDC, 15W @ 2-pair IEEE 802.3af PoE
• Output PoE Power Pin Assignment (Port 1-2): 12(-), 36(+), 45(+), 78(-)
• Output PoE Power Pin Assignment (Port 3-4): 2-pair PoE: 45(+), 78(-), 4-pair PoE: 12(+), 36(-), 45(+), 78(-)
• Output Power per DC Port: 1 x 12VDC@2.5A, 1 x 24VDC@1.25A
• System Power Consumption (without PoE): 5W
• PoE Output Power Budget: 150W
• Surge Protection per PoE Port: 6KV
• Surge Protection for AC power: 10KV

Mechanical & Environmental:

• Operating Temperature: -40°C~ 65°C (-40°F~ 149°F)
• Storage Temperature: -40°C~ 85°C (-40°F~ 185°F)
• Operating Humidity: 5% ~ 95% non-condensing

Dimensions (L x W x H): 10 x 7.86 x 3.74 inches
